980nm semiconductor laser surgical laser Filter

DETAILS


980nm semiconductor laser surgical laser Filter

The scope of application of the 980nm laser filter matching equipment is: used in medical institutions for the treatment of benign prostatic hyperplasia in urology.

The 980nm laser can be absorbed by both water and hemoglobin simultaneously and in balance, which has the best tissue cutting effect and the best hemostatic effect compared to the breakthrough of only absorbing laser to water or hemoglobin alone. The clinical performance is characterized by the fastest vaporization, cutting of soft tissue, less bleeding, and clear surgical vision without bleeding.

In the water environment, the working range of the 980nm red laser surgical system is within 2mm of the front end of the optical fiber, and tissues outside the 2mm range of the front end of the optical fiber will not be damaged, which is quite safe for operation. It achieves non-contact cutting and hemostasis, and achieves various forms of hemostasis by adjusting the distance between the fiber head and the target, achieving the desired therapeutic goal.

The medical instrument compatible with the 980nm laser filter has fast cutting speed and stable laser energy; The medical instrument compatible with the 980nm laser filter has good hemostatic effect, which can achieve point-to-point hemostasis or non-contact hemostasis.

ItemParameters
Product name980nm semiconductor laser surgical laser Filter
Model numberBP980
Centralwavelength:(CWL)980±5nm
FWHM10±3nm
TransmittanceT>85%
Blocking Rate>OD3-OD6  UV-NIR
Blocking Band200nm-1200nm
Raw materialB270 or Corning gorilla glass or other optical glass
Surface quality(S/D)60/40 or better
DimensionCustomized
Thicknesscustomized

02 980nm semiconductor laser surgical laser lens.jpg
