Product Features

Material: N-BK7 optical glass is used, which has high transparency and low dispersion characteristics, suitable for visible light and near-infrared bands.

Structure: Common hexagonal or square designs, hexagonal light guide tubes can reduce light loss by 35%, suitable for high-precision uniform light requirements.

Processing accuracy: The surface flatness can reach λ/8, the angle tolerance is ± 15 arc seconds, and it supports customized dimensions (such as 2mm to 50mm aperture).

Application scenarios

Laser beauty device: used as a light guide block for IPL/E optical equipment, it needs to be used in conjunction with a sapphire window to improve durability.

Stage lighting: Light guide columns or prisms are used for light refraction and homogenization, such as octagonal prism lenses.

Industrial optics: used for homogenizers, beam splitters, etc., such as TECHSPEC ® Series uniform optical tube.

Precautions

Coating options: Some products offer anti reflective coatings (AR coatings) to reduce reflection losses.

Cleaning and maintenance: Avoid scratching the surface, and it is recommended to use specialized optical cleaning methods.

Please tell us the material, size, laser power, application before quote.
