Product Features

Material and Performance

Using N-BK7 glass substrate, it has high transparency (visible to near-infrared transmittance of over 92%) and low dispersion characteristics (Abbe number ν d ≈ 64.17), suitable for precision optical applications.

The hexagonal structure design can reduce light loss by up to 35%, which is superior to square light guides.

Application scenarios

Used for OEM lighting, laser ranging, stage lighting and other scenarios to achieve uniformity of non-uniform light sources.

The encapsulated version (such as a corner prism retroreflector) supports high-precision retroreflection and is suitable for industrial or outdoor environments.

Technical Specifications

Surface quality: Polish to 60-40 scratch pitting standard, parallelism ≤ 5 arc minutes.

Dimensional tolerance: Length ± 3mm, aperture ± 10mm, suitable for different NA value light source requirements.

Precautions

Cleaning and maintenance: Use a soft cleaning cloth and specialized cleaning agent to clean and avoid scratching the surface.

Storage environment: Store in a dry, well ventilated environment to prevent moisture and mold.

Usage: During use, avoid severe vibration and collision to avoid affecting its optical performance.

Please tell us the material, size, laser power, application before quote.
