Features

High purity and stability: After selection and remelting, fused silica has few impurities, high purity and good stability for most chemicals.

Good transparency: It has good transparency in the range of ultraviolet to infrared light, especially suitable for UV LED lighting sources.

Efficient luminous flux: Adopting a hexagonal structure design, it can reduce light loss by 35% compared to a square structure, maximizing luminous flux.

Application fields

Optical instruments: used in optical instruments to help achieve uniform distribution of light sources.

LCD display: As a component of the backlight source, it provides uniform backlight.

Advertising lightbox: Make the light of ultra-thin advertising lightboxes more uniform.

Medical equipment:such as X-ray scanners, provides a clear and uniform light source.

Lighting Engineering: Used for the application of light efficiency in flat panel lighting and bright light engineering.

Luminous signage: Ensure uniform lighting of the signage to improve visibility.

Technical Specifications

Numerical aperture (NA): Light sources with smaller numerical aperture values require longer light pipes to homogenize the light, while light sources with larger numerical aperture values can meet the requirements using shorter light pipes.

Material: usually made of UV fused silica, suitable for UV LED lighting source.

Precautions for use

Fixed and integrated: In order to facilitate fixation and integration, some light guide blocks are equipped with specialized interfaces.

Operating environment: During use, attention should be paid to avoiding severe vibrations and collisions to prevent damage to the light guide block. At the same time, it is necessary to keep its surface clean and avoid pollutants such as dust and oil stains from affecting its transparency.

Please tell us the material, size, laser power, application before quote.
